Seafood Tunnel Iqf Freezing Technology Ultra Low Temp Freezer 2000kgs/H 2500kgs/H Vegetable

DJL vegetable and fruits freezing lines / flash freezing equipment tunnel freezer

Using liquid nitrogen for quick freezing not only has a very fast freezing speed, but also preserves the taste and nutrition of food to the utmost extent. In addition, nitrogen, as a gas in the air, is non-toxic, tasteless and very safe.In addition, compared with the tunnel-type quick-freezer, the cabinet-type machine occupies less area and is more convenient to use. It is more suitable for enterprises with low output and high product value.

Model	Tunnel length (mm)	Wire belt width (mm)	Tunnel height (mm)	Power (KW)	freezing capacity (kg/h)
DJL-QFL-1206	6000	1200	1750	10	400-600
DJL-QFL-1209	9000	1200	1750	12	800-1000
DJL-QFL-1212	12000	1200	1750	18	1000-1200
DJL-QFL-1609	9000	1600	1750	15	1000-1200
DJL-QFL-1612	12000	1600	1750	28	1800-2100
DJL-QFL-1618	18000	1600	1750	32	2000-2500
DJL-QFL-1815	15000	1800	1750	28	2000-2500
DJL-QFL-1818	18000	1800	1750	32	2200-2800
DJL-QFL-1824	24000	1800	1750	46	2800-3500

Seafood Tunnel Iqf Freezing Technology Ultra Low Temp Freezer 2000kgs/H 2500kgs/H Vegetable

Liquid nitrogen quick freezing system diagram

1.liquid nitrogen freezing tunnel

2.liquid nitrogen tank

3.tank base

4.exhaust duct

5.exhaust fan

6.liquid nitrogen pipeline

Equipment material:	SUS304 stainless steel
Working temperature:	-150℃~room temperature
Temperature control precision:	±2℃
Temperature uniformity:	±5℃
Cooling rate:	≥20℃/min
Heating rate:	≥5℃/min
Distribution specification:	380V/50HZ

Our Advantages

1.More than 10 years of professional recognition for ultra-low temperature deep cooling ,own independent intellectual property rights with more than 10 patented technologies.

2.The ability of compound innovation and multi-technology integration makes DJL unique in freezing machine industry.

3.Personalized scheme provides you the best cost performance of product

4.Close cooperative relationships with many universities

5.Three minutes quick-freezing ,the temperature low to minimum -196℃

6.Reasonable &exclusive quick-freezing total solution maximize utilize/save customers cost.

7.Free experiment and verification supporting .

8.Better serving customers by setting up branches and offices in country's areas.

Certifications

FAQ

1. How much liquid nitrogen will be consumed for freezing foods?

Generally 1:1, that is 1 ton nitrogen for 1 ton food The comsumption rate is 1:1 to 1:1.5, actual consumption depends on the dimension and water content.

2. What is your warranty policy?

One year warranty, life-time maintenance.Components and parts are provided for free within warranty date for replacement.
